GM400E high shear grout mixer
GM400E grout mixer is a high speed high shear grout mixer. It has been designed for use either in conjunction with a conventional paddle mixer and pump or by virtue of its own built in impeller pump, as a stand-alone mix and place machine. The unit will rapidly and efficiently mix various types of grout which can include cement, bentonite and sand. It is specially design for cement mixing and grouting in ground/underground engineering. We also can design the mixer with agitator, to make the mixing work can continuously be done.
Mobile Phone:
86-13939067523
E-mail:
[email protected]
The unit will rapidly and efficiently mix various types of grout which can include cement, bentonite and sand. It is specially design for cement mixing and grouting in ground/underground engineering. We also can design the mixer with agitator, to make the mixing work can continuously be done.
| Item | Technical data |
| Rated capacity | 400 liter |
| Acceptable W/C ratio | ≥0.5:1 |
| Mixing time | 3 min |
| Power | 7.5kW |
| Weight | 400 kgs |
| Overall Dimension | 1500x1100x1500mm |
It is mainly used for ground and underground engineering construction, such as roads, railways, hydropower, construction, and mines.
Building structure
Building and bridge repair, foundation reinforcement, slope support, soil compaction, rock grouting..
Civil engineering
Dam, tunnel, subway, mine, soil nailing wall, curtain. Anchor, cable trench and anchor grouting.
Engineering
Underwater foundation, offshore platform, coast foundation grouting reinforcement.
Mine application
Roadway reinforcement, backfill, waterproof grouting. Acted as a grouting plant in the Pipe Jacking Machine.
